The Highfield Patrol 760 is a 25-foot rigid inflatable built on an aluminum hull constructed from 4 mm 5083 aluminum plate with 6 and 10 mm stringers. The design centers on a super deep V hull with wide chines and large diameter tubes, engineered for high maneuverability and a smooth, dry ride in rough conditions. Powered by a single Yamaha or Mercury 300 hp engine, the boat planes readily despite modest horsepower and is built to carry substantial loads.
The Patrol 760 combines long-range fuel capacity with a modular design that adapts to different uses—whether family cruising, charter operations, or commercial work. The wide beam of 9.5 feet supports stability and usable deck space. The modular layout option allows customization to meet specific operational requirements.
Construction emphasizes durability and structural integrity. The deep V hull design and robust tube construction work together to deliver handling and seaworthiness across varying sea states.
Length
25.00 FT
Beam
9.50 FT
Weight
2,161 LBS
Material
Aluminum
Engines
1
Engine Make
Yamaha/Mercury
Power
NaN HP
Fuel
75 GAL
